Setting Up OpenAdmin Tool (OAT) on Mac OS



Introduction



The Open Admin Tool (OAT) is an open source web-based administration tool for Informix Dynamic Server (IDS). It is a web console where users can manage dbspaces, schedule tasks and monitor MACH 11 clusters etc. through their web browsers.



OAT is a web console that is hosted on a single web server. Other machines that have access to the web server’s network can simply open up a web browser, type in the web server machine’s URL, and they can use OAT to manage their database servers.



In order to host the Open Admin Tool website, the following prerequisites have to be setup:



1. Informix Client SDK or Informix Connect
2. A web server, such as Apache 2.0.
3. PHP 5.2.4 dynamically loaded as an Apache 2.0 module. It also has to have the following extensions enabled
• Pcre
• Pdo
• Pdo_sqlite
• Pdo_informix
• Soap
• Gd   (requires libpng and libjpeg libraries)
• Openssl  (requires libssl and libcrypto libraries)
• Sockets
• Libxml  (requires libxml2 libraries)
• Session
• Simplexml



The Open Admin Tool can be hosted on any platforms that have all of the above setup.



This article will provide the steps on how to setup OAT on a Mac OS X Platform.



Setting up Open Admin Tool (OAT) on Mac OS



First step is to install Informix Client SDK for Mac OS.



The Mac OS will already have an Apache web server installed. We can use the Apache web server that comes with Mac OS. We do not need to install other web servers.



The Mac OS will also have an installed PHP, however the PHP that comes with Mac OS does not have all the extensions that OAT requires. We cannot use the PHP that comes with Mac OS. We have to compile PHP binaries from source.



Our goal here is to build our own PHP binaries and dynamically load it to the Apache web server that comes with Mac OS.



Compiling PHP on Mac OS



Before starting to compile PHP, make sure that you have libpng, libjpeg, openssl and libxml2 installed into /usr/local/ or /usr/. Some PHP extensions require these libraries in order to compile.



Obtain the latest PHP source code from php.net (http://www.php.net/downloads.php). Decompress the source code package and issue the following commands.



cd /path/to/php/source/code



./configure --prefix=/path/to/where/you/want/to/install/php --with-apxs2=/usr/sbin/apxs --enable-soap --enable-pdo --with-pdo-sqlite --with-gd --with-pcre-regex --enable-session --with-openssl --enable-sockets --enable-libxml --enable-simplexml



make





The “configure” command will generate a makefile specific to your machine’s build environment. The “make” command will use the generated makefile to create PHP binaries.



The “configure” and “make” command will not always run smoothly. It is dependent on your machine’s setup. Please see the following section about debugging the “configure” command for more information.



If the “configure” and “make” command ran smoothly, you can run the “make install” command. This command will copy the php binaries to /path/to/where/you/want/to/install/php. It will also overwrite the PHP apache handler (the glue between Apache and PHP, called libphp5.so) at /usr/libexec/apache2/. You may want to backup the Mac OS’s default libphp5.so before running “make install”



##Be sure that you have backed up /usr/libexec/apache2/libphp5.so##

make install



After the “make install” command, the php binaries can be found under /path/to/where/you/want/to/install/php/.



Right now we have compiled the PHP binaries that have all the extension modules that OAT requires, EXCEPT the pdo_informix extension. This extension DOES NOT come with PHP source code from php.net. We have to compile it from source code separately from PHP, and enable it as a dynamic PHP extension module. We will go through the process of compiling pdo_informix in the later section “Compiling pdo_informix extension and enabling it in PHP”.



Right now we also have compiled the PHP apache handler (the glue between PHP and apache). This will appear as a file called “libphp5.so”, under /usr/libexec/apache2/. This file will be loaded as a dynamic Apache module. This will be described in the later section “Enabling PHP in Apache”



The next thing you have to do is to create a php configuration file. Copy the sample php.ini file from /path/to/php/source/code/php.ini-dist to /path/to/where/you/installed/php/lib



cd /path/to/php/source/code/

cp ./php.ini-dist /path/to/where/you/want/to/install/php/lib/php.ini



Then edit the php.ini file. Make the following changes to the php.ini file.



memory_limit = 128M Change this to à memory_limit = 300M

extension_dir = "./"     Change this to à extension_dir = “/path/to/where/you/installed/php/lib/extensions”



OAT requires a greater memory limit. Thus we increased the memory limit here.



The extension_dir is the directory where dynamic PHP extension modules will reside. Dynamic PHP extensions have to be placed under extension_dir, and enabled in the php.ini configuration file. The pdo_informix extension module will be handled in this fashion.



Debugging Information about the “configure” and “make” command



The --prefix tag lets you specify where you want to install the php binaries. You have to make sure that you have the write permissions to that directory before configuring PHP.



The --with-apxs2 tag lets you specify where to find your apache binaries, so that the apache handler (i.e. the glue between Apache and PHP) can be built. This apache handler will appear as a file called “libphp5.so” after the compilation. It will appear under /usr/libexec/apache2/. This document will talk about how to dynamically load this handler to the Apache web server in the later section “Enable PHP in Apache”. Here we are using the Mac OS default Apache web server, thus this flag should be set to point to /usr/sbin/apxs.



The --enable and --with flags specify what extensions you want to enable. Pdo_informix will be enabled separately after we compile the PHP binaries.



The “configure” and “make” command will not always run smoothly. One possible reason is that the prerequisite libraries are not present. For example, the php gd extension will not compile if libpng and libjpeg libraries are not found on your machine. The openssl extension will not compile if libssl and libcrypto libraries are not found. The libxml extension will not compile if libxml2 libraries are not found. Make sure that you have libpng, libjpeg, openssl and libxml2 installed into /usr/local/ or /usr/ before running the configure command.



Another possible reason is that the library architecture and the compilation flag do not match. If your libpng, libjpeg, libssl, libcrypto and libxml libraries are in 32bit mode, you have to set the compilation flag CFLAGS to –m32. If your libraries are in 64bit mode, you have to set CFLAGS to –m64. For example, if you want to see whether your libxml2 library is 32bit/64bit, run the following commands:



cd /usr/lib



file libxml2.2.dylib



##If your libraries are 64bit, set CFLAGS to be –m64##

setenv CFLAGS –m64



##If your libraries are 32bit, set CFLAGS to be –m32##

setenv CFLAGS –m32



If you encounter problems, you can look into the config.log file generated by the configure script. You can also open up the configure script (i.e. /path/to/php/source/code/configure) or the makefile (i.e. /path/to/php/source/code/Makefile) with a text editor, search for the error message and debug the problem. Sometimes the configure script cannot find libraries because they are not installed on /usr/ or /usr/local/. In that case, hardcoding your library paths to the configure script’s library search path will solve the problem.



You may also add the --disable-all tag to the configure command. This will disable all other extensions that we did not specify in the configure command. Compiling fewer extensions will give us fewer errors. Since OAT doesn’t require those extra extensions, it is okay to add the --disable-all flag.



Compiling PDO_INFORMIX extension and enabling it in PHP



Download the latest pdo_informix source code from http://pecl.php.net/package/PDO_INFORMIX



Before you compile pdo_informix. Make sure that CFLAGS are set accordingly. If your Client SDK/IConnect libraries are 32bit, then set CFLAGS to be –m32. If your Client SDK/IConnect libraries are 64bit, then set CFLAGS to be –m64



Decompress the pdo_informix source code and run the following commands



cd /path/to/pdo_informix/source/code/



/path/to/where/you/installed/php/bin/phpize



./configure --with-php-config=/path/to/where/you/installed/php/bin/php-config –with-pdo-informix=/path/to/where/you/installed/ClientSDK/or/IConnect/



make



This compiles the pdo_informix extension module. It will appear as a file “pdo_informix.so” under /path/to/pdo_informix/source/code/modules/



Copy pdo_informix.so to the PHP extension_dir ( We have set this to be /path/to/where/you/installed/php/lib/php/extensions/ in previous sections)



cd /path/to/pdo_informix/source/code/modules/

cp ./pdo_informix.so /path/to/where/you/installed/php/lib/php/extensions/



Add the following line to the php.ini configuration file (Under /path/to/where/you/installed/php/lib/php.ini)



extension=pdo_informix.so



This will enable the pdo_informix extension in PHP.



Enabling PHP in Apache



After PHP has been built successfully, the PHP apache handler (the glue between PHP and apache) will be created. This will appear as a file called “libphp5.so”, under /usr/libexec/apache2/



We have to edit the Apache configuration file (httpd.conf) to load the libphp5.so. This can be done by adding the following three lines in /etc/apache2/httpd.conf. These lines might already exist in the httpd.conf but are commented out. In that case you only have to uncomment them.



LoadModule php5_module libexec/apache2/libphp5.so

AddType application/x-httpd-php .php

AddType application/x-httpd-php-source .phps





You also have to setup the Apache environment variables. You will have to edit the /usr/sbin/envvars file. Add the following lines in the envvars file.



INFORMIXDIR=”/path/to/IConnect/or/CSDK/installation/”

export INFORMIXDIR



PATH=”$INFORMIXDIR/bin:$PATH”

export PATH



DYLD_LIBRARY_PATH=”$INFORMIXDIR/lib: $INFORMIXDIR/lib/cli: $INFORMIXDIR/lib/esql: $INFORMIXDIR/incl: $INFORMIXDIR/incl/cli: $INFORMIXDIR/incl/esql: /usr/lib: $DYLD_LIBRARY_PATH”

export DYLD_LIBRARY_PATH



You may now start the Apache web server. Issue the following command with root user access permissions.



/usr/sbin/apachectl –f /etc/apache2/httpd.conf –k start





Unpack OAT source code at /Library/WebServer/Documents/OpenAdminTool. The ownership of all files under this directory has to be changed too. Make sure these files are owned by the user and group that runs apache. (These should match the user and group settings in /etc/apache2/httpd.conf)



Visit http://<hostname>.<domainname>//OpenAdminTool/index.php and continue with the OAT web install. OAT should be operational after the OAT web install.

Leo Chan



The GLSLIB is a library that is used to internationalize IBM Informix products such as IBM Informix Dynamic Server and IBM Informix Client SDK. Each IBM Informix product is bundled with a specific version of GLSLIB. This GLS library supports English, Western European, Eastern European, Asian and African languages. Additional Locales that are not included in the GLS library can be installed from the International Language Supplement (ILS). ILS provides all available GLS locales and code-set conversion files. It also includes error messages to support several languages. The important point about ILS is that it is a platform independent product. The languages supported by ILS are Czech, German, French, Spanish, Russian, Polish, Slovak, Japanese, Simple Chinese, Traditional Chinese and Korean.

The following tables provide information about the version of GLSLIB - bundled with IBM Informix Dynamic Server and IBM Informix Client SDK. It also provides the information about the version of ILS that is compatible with the specific version of IBM Informix product.

The table can be used to
1) Find the version of GLS library bundled with the specific version of IBM Informix product.
2) Determine the compatible version of ILS that should be used with the specific version of IBM Informix product.



IDS Version GLSLib Version Compatible ILS Version 3.13 4.00 4.50 xC3 xC5 xC1 xC2 xC4 xC5 xC6 xC7 xC8 xC9 xC10 xC1 xC2 xC3 7.31.xD6 X 2.40.MCx 7.31.xD6W2 X 7.31.xD7 X 7.31.xD8 X 7.31.xD9 X 7.31.xD10 X 9.40.xC1 X 3.40.MCx 9.40.xC5 X 9.40.xC6 X 9.40.xC7 X 9.40.xC7W1 X 9.40.xC7W2 X 9.40.xC7W3 X 9.40.xC7W4 X 9.40.xC7W5 X 9.40.xC7W6 X 9.40.xC7W7 X 9.40.xC9 X 10.00.xC1 X 3.40.MCx 10.00.xC3W2 X 10.00.xC3W3 X 10.00.xC3W4 X 10.00.xC3W5 X 10.00.xC4 X 10.00.xC4W1 X 10.00.xC4W2 X 10.00.xC4W3 X 10.00.xC5W1 X 10.00.xC5W2 X 10.00.xC5W3 X 10.00.xC5W4 X 10.00.xC5W5 X 10.00.xC6 X 10.00.xC6W1 X 10.00.xC6W2 X 10.00.xC6W3 X 10.00.xC6W4 X 10.00.xC6W5 X 10.00.xC7 X 10.00.xC7W1 X 10.00.xC7W2 X 10.00.xC8 X 11.10.xC1 X 3.50.MC1 11.10.xC2 X 11.10.FC2W1 X

CSDK Version GLSLib Version Compatible ILS Version 3.13 4.00 4.50 xC3 xC5 xC1 xC2 xC4 xC5 xC6 xC7 xC8 xC9 xC10 xC1 xC2 xC3 2.90.xC1 X 3.40.MCx 2.90.xC3 X 2.90.xC4 X 3.00.xC2 X 3.50.MC1 3.00.xC3 X 3.50.xC1 X
